| Type | Motor | Rated | Frequency (HZ) | Current (A) | Power (W) +10%~-20% | Speed (min)-1 | Ma | Static | Noise (dB) | Curve | Capacitor (uF) | |
| CFM | m3/h | |||||||||||
| C2S-225.63C | M2S9203-AF | 115 | 50 | 1.30 | 130 | 2650 | 708 | 1200 | 540 | 68 | 1 | 10.0/250 |
| 60 | 1.45 | 171 | 2950 | 790 | 1340 | 730 | 71 | |||||
| C2E-225.63C | M2E9203-AF | 230 | 50 | 0.60 | 131 | 2650 | 708 | 1200 | 540 | 68 | 1 | 4.0/450 |
| 60 | 0.74 | 170 | 2950 | 790 | 1340 | 730 | 71 | |||||
| C2D-225.63C | M2D9203-AF | 380 | 50 | 0.34 | 131 | 2650 | 708 | 1200 | 540 | 68 | 1 | 2.0/630 |
| 60 | 0.45 | 170 | 2950 | 790 | 1340 | 730 | 71 | |||||
